Vortice UV-Logika System
Kills pathogens, without any ozone emission.
Germicidal UV-C lamp
Model: UV-LOGIKA System
Order Code: See technical data for further details
Germicidal installation lamp radiates UV-C ultraviolet light at a constant wavelength of 253.7 nm
Features
- Casing in anodized extruded aluminium
- Sides in die-cast aluminium painted with silicone polyester paint
- Internal side walls in die-cast aluminium
- A reflective parabola in aluminium sheet with a special treatment capable of increasing the reflective capacity by more than 90%
- Sheet metal bracket for wall/ceiling attachment
UV Lamp Consists of:
- internal protective coating able to maintain the effectiveness of germicidal radiation unaltered over time
- Envelope glass is capable of filtering ozone, avoiding its emission into the environment.
- A special transformer housed in the product casing is capable of ensuring the constant flow of electricity and keeping the wavelength constant, avoiding power fluctuations that could reduce the effectiveness of the disinfection process.
Applications
- Healthcare sector: pharmacies, waiting rooms for dental offices, medical offices, rehabilitation and physiotherapy centres
- Services industry: bathrooms of petrol stations, railway stations, airports, shops, bars, restaurants, post offices, hairdressers, beauty centres, school classrooms
- Fitness sector: gyms, yoga rooms, locker rooms
- Industrial sector: sheds, offices, warehouses
Advantages
Safety: full compliance with the regulations relating to the safety of lighting equipment. The adopted UV-C lamp does not emit ozone.
Effectiveness: the germicidal action exerted by UV-LOGIKA SYSTEM takes place in a relatively short time. A special electronic device (ballast) integrated into the product ensures the constancy of the wavelength of the radiation emitted to guarantee the effectiveness of the germicidal action over time.
Environmental sustainability: effectively sanitises surfaces without releasing any chemical substance into the atmosphere.
Comfort of use: UV-C radiation is odourless, does not involve the emission of gas or other compounds harmful to health and does not create polluted air flows when used in dusty environments.
Long life: the robust structure of the aluminium casing and the high quality of the UV-C lamp ensure its regular operation over time.
Low operating costs: the low consumption (36 W) and the long life of the UV-C lamp (9,000 h nominal) are fully compatible with the prolonged use of the product.
Germicidal installation lamp is designed to radiate UV-C ultraviolet light at a constant wavelength of 253.7 nm, ideal for the neutralisation of pathogens, without any ozone emission.
Advantages
Safety: full compliance with the regulations relating to the safety of lighting equipment. The adopted UV-C lamp does not emit ozone.
Effectiveness: the germicidal action exerted by UV-LOGIKA SYSTEM takes place in a relatively short time. A special electronic device (ballast), integrated in the product, ensures the constancy of the wavelength of the radiation emitted, to guarantee the effectiveness of the germicidal action over time.
Environmental sustainability: effectively sanitises surfaces without releasing any chemical substance into the atmosphere.
Comfort of use: UV-C radiation is odourless, does not involve the emission of gas or other compounds harmful to health and does not create polluted air flows when used in dusty environments.
Long life: the robust structure of the aluminum casing and the high quality of the UV-C lamp ensure its regular operation over time.
Low operating costs: the low consumption (36 W) and the long life of the UV-C lamp (9,000 h nominal) are fully compatible with the prolonged use of the product.
