Duct Heater
Galvanised steel ventilation heater to install in the ventilation system.
Model: AH Series
Order Code: See technical data for further details
Galvanised steel ventilation heater to install in the ventilation system.
- Suitable for mono-phase and three-phase systems.
- Galvanised steel box, stainless steel electrical resistances carried by tubular duct in galvanised steel.
- Automatic security thermostat set at 60°C (±15%) linked in a series with a second security thermostat with manual reset set at 120°C (± 15%).
- Operative temperature from –30°C to 50°C (not suitable with powders or chemical agents).
- Minimum air volume is based on a minimum air speed of 2m/s.
To be installed in the ventilation system, always after the fan and /or the noise attenuator/air filter.
| Model | Code | A | B | C | D | E | F |
| AH100 | ALV22793 | 100 | 185 | 325 | 100 | 40 | 230 |
| AH125 | ALV22797 | 125 | 225 | 325 | 125 | 40 | 230 |
| AH150 | ALV22759 | 150 | 250 | 380 | 150 | 40 | 285 |
| AH200 | ALV22790 | 150 | 300 | 380 | 200 | 40 | 285 |
| AH250 | ALV22791 | 150 | 350 | 380 | 250 | 40 | 285 |
| AH315 | ALV22792 | 150 | 415 | 380 | 315 | 40 | 245 |
| H3-315 | ALV22779 | 150 | 415 | 380 | 315 | 40 | 240 |
Automatic security thermostat set on 60 °C (±15%) linked in a series with a second security thermostat with manual reset set on 120 °C (± 15%). Operative temperature from –30 °C to 50 °C (not suitable with powders or chemical agents). Minimum air volume is based on a minimum air speed of 2m/s.
