Medium Pressure Centrifugal Fans (MA 26-31)
Medium Pressure Centrifugal Fans
- Cast aluminium housing.
- Cast aluminium forward blades casing.
- Polyester finishing coat.
- Standard asynchronous squirrel-cage motor with IP-55 protection and Class F insulation.
- Manufactured with standard voltages: 230V 50Hz in single phase motors and 400V 50Hz in three-phase
motors. - Default assembly orientation is LG270
APPLICATIONS
- Designed for inline installation, they are suitable for:
- Industrial applications, air extraction or injection.
- Cooling of machines and parts.
- Clean and slightly dusty air transport.
- Maximum working temperature: carried air 130ºC; environment: 60ºC for three phase motors and 50ºC for single phase motors.
| Model | RPM | V | Hz | kW | Phase | Air flow m3/h |
In-duct dBA@3m | Weight Kg |
| MA 26 M2 0,37kW | 2800 | 230 | 50 | 0.37 | 1 | 750 | 63 | 13 |
| MA 26 T2 0,37kW | 2800 | 400 | 50 | 0.37 | 3 | 750 | 63 | 13 |
| MA 27 T2 0,55kW | 2800 | 400 | 50 | 0.55 | 3 | 860 | 66 | 14 |
| MA 28 T2 1,1kW | 2800 | 400 | 50 | 1.1 | 3 | 1450 | 68 | 20 |
| MA 31 T2 2,2kW | 2800 | 400 | 50 | 2.2 | 3 | 2170 | 72 | 30 |
