VRC Series
Centrifugal Roof Mounted Exhaust
Model: VRC
Order Code: See technical data for further details
This series is available in single-phase and 3-phase power.
Single-phase power uses external rotor motors with speed control.
3-phase power requires a step speed controller with external rotor motors.
Model
Code
Power kW
FLA
Phase
Speed RPM
dBA
@ 3m
VRC190-2E
ALV841
0.052
0.23
1
2350
40
VRC220-2E
ALV1634
0.085
0.38
1
2600
51
VRC220-4E
ALV891
0.05
0.25
1
1380
36
VRC280-4E
ALV847
0.078
0.35
1
1420
43
VRC280-6E
ALV848
0.038
0.35
1
960
35
VRC315-4E
ALV849
0.115
0.5
1
1430
45
VRC315-6E
ALV880
0.06
0.5
1
960
39
VRC355-4E
ALV881
0.245
1.12
1
1420
45
VRC355-6E
ALV882
0.07
0.31
1
870
39
VRC400-4E
ALV883
0.48
2.4
1
1370
49
