IVRD Series
Car park ventilation setting the standard in thrust and weight.
Model: IVRD Series
Order Code: See technical data for further details
Quiet and universal in application. Suitable for ventilation of car parks with ambient temperature from up to 40 degrees celsius.
Features
- Low noise emission
- Maximum thrust
- Easy and fast to install due to lightweight, aluminium construction
- Direct driven, centrifugal
High quality, powerful jet fan with optimal dimensions for minimum space.
Casing
Casing from corrosion-resistant aluminium in compact design. Aerodynamically-shaped inlet cone. Permanently optimal surface protection by steel-powder coating.
Impeller
High efficient centrifugal impeller with welded, backward-curved blades. Dynamically balanced according to DIN ISO 1940-1, balancing quality 6.3.
Motor
IEC 3-phase standard motor protection to IP 55.
Installation
Assembly bracket integrated as standard. They are attached directly to the ceiling by means of rawl plugs (accessories, to be provided on site) at four fastening points. To avoid vibration transmission the use of anti-vibration mounts is recommended.
Electrical Connection
Terminal box from polymer fitted externally on casing as standard (IP 55).
| Model | Code | Thrust | Discharge Speed | Max. Air Flow Volume | RPM | Sound Pressure Level | Nominal Motor Power | Current Full Load |
Phase | Nominal Weight ca. |
| N | m/s | V m3/h | min-1 | dBA | kW | Amps | kg | |||
| IVRD 500/4 | ALV1104 | 42 | 21 | 6100 | 1440 | 55 | 1.5 | 3.3 | 3 | 63 |
| IVRD 560/4 | ALV1105 | 75 | 25.2 | 8900 | 1420 | 58 | 2.2 | 4.6 | 3 | 71 |
